D-LINK DGS-1100-24PV2 24 Ports Manageable Ethernet Switch - 2 Layer Supported - Twisted Pair
SKU DGS-1100-24PV2
1 / 1At a glance
The D-LINK DGS-1100-24PV2 24 Ports Manageable Ethernet Switch - 2 Layer Supported - Twisted Pair (part number DGS-1100-24PV2) is supplied to trade with pricing on enquiry.
MPNDGS-1100-24PV2
Delivery time1 to 2 days
Product information
Product details2 facts
| MPN | DGS-1100-24PV2 |
|---|---|
| Delivery time | 1 to 2 days |
Management features5 facts
| Switch type | Managed |
|---|---|
| Switch layer | L2 |
| Quality of Service (QoS) support | Yes |
| Web-based management | Yes |
| System event log | Yes |
Ports & interfaces1 fact
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
|---|
Network15 facts
| Networking standards | IEEE 802.1AX, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1w, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z |
|---|---|
| 10G support | No |
| Copper ethernet cabling technology | 10BASE-T, 10BASE-TX, 1000BASE-T |
| Port mirroring | Yes |
| Full duplex | Yes |
| Flow control support | Yes |
| Link aggregation | Yes |
| Broadcast storm control | Yes |
| Rate limiting | Yes |
| Auto MDI/MDI-X | Yes |
| Spanning tree protocol | Yes |
| Head-of-line (HOL) blocking | Yes |
| Auto-negotiation | Yes |
| VLAN support | Yes |
| Virtual LAN features | Port-based VLAN, Voice VLAN |
Data transmission4 facts
| Switching capacity | 48 Gbit/s |
|---|---|
| Store-and-forward | Yes |
| Jumbo frames support | Yes |
| Packet buffer memory | 4.1 MB |
Security4 facts
| DHCP features | DHCP client |
|---|---|
| IGMP snooping | Yes |
| Security algorithms | SNMP, SSL/TLS |
| Queue scheduling algorithms | SPQ, Weighted Round Robin (WRR) |
Multicast features1 fact
| Multicast support | Yes |
|---|
Design3 facts
| Rack mounting | Yes |
|---|---|
| Product colour | Black |
| LED indicators | Yes |
Performance7 facts
| Built-in processor | Yes |
|---|---|
| Processor frequency | 125 MHz |
| Memory type | DRAM |
| Flash memory | 16 MB |
| Noise level | 0 dB |
| Fanless | Yes |
| Mean time between failures (MTBF) | 255003 h |
Power2 facts
| AC input voltage | 100 - 240 V |
|---|---|
| Power consumption (max) | 19.5 W |
Power over Ethernet (PoE)3 facts
| Power over Ethernet (PoE) | Yes |
|---|---|
| Power over Ethernet (PoE) power per port | 30 W |
| Total Power over Ethernet (PoE) budget | 100 W |
Operational conditions4 facts
| Operating temperature (T-T) | -5 - 50 °C |
|---|---|
| Storage temperature (T-T) | -40 - 70 °C |
| Operating altitude | 0 - 2000 m |
| Heat dissipation | 107.5 BTU/h |
Weight & dimensions4 facts
| Width | 280 mm |
|---|---|
| Depth | 230 mm |
| Height | 44 mm |
| Weight | 2.2 kg |
Specifications as listed in our catalogue. Rows naming a price, rating, review or rank are never shown.
